Product Description:
The DC Buck Boost Converter is a type of DC-DC converter that can operate in both buck and boost modes. This means that the converter can step up or step down the input voltage to produce the desired output voltage. The topology of this converter is a buck-boost topology, which is a type of non-isolated topology that can produce output voltages that are either higher or lower than the input voltage.
The output voltage of the DC Buck Boost Converter can be adjusted from 1.25V to 35V, making it ideal for a wide range of applications. For example, the converter can be used as a buck boost converter 3.3v to provide a stable power supply for microcontrollers and other low-power devices. Alternatively, the converter can be used as an auto buck boost converter to maintain a steady output voltage even when the input voltage fluctuates.
The DC Buck Boost Converter is also an excellent choice for battery charging applications. The converter can be used as a buck boost converter for battery charging, allowing you to charge batteries with voltages that are either higher or lower than the input voltage. This makes the converter ideal for use in portable electronics and other battery-powered devices.
In summary, the DC Buck Boost Converter is a versatile and efficient converter that can be used in a wide range of applications. With its ability to operate in both buck and boost modes, and with its adjustable output voltage range of 1.25V to 35V, this converter is ideal for use as a buck boost converter 3.3v, an auto buck boost converter, and a buck boost converter for battery charging. The converter's overcurrent, overvoltage, and overtemperature protection features also make it a safe and reliable choice for any application.
Features:
- Product Name: DC Buck Boost Converter
- Output Current Range: Up To 2A
- Efficiency: Up To 95%
- Output Current: 2A
- Protection Features: Overcurrent, Overvoltage, Overtemperature
- Topology: Buck-Boost
- Keywords: 5v buck boost, dc dc buck and boost converter, buck and boost converter
Technical Parameters:
| Technical Parameter |
Value |
| Output Voltage |
1.25V-35V |
| Switching Frequency |
400kHz |
| Output Voltage Range |
1.25V-35V |
| Package Type |
SOT-23-6 |
| Control Method |
PWM |
| Topology |
Buck-Boost |
| Operating Temperature Range |
-40°C To +85°C |
| Input Voltage Range |
3.5V-32V |
| Efficiency |
Up To 95% |
| Input Voltage |
3.5V-32V |
Applications:
The DC buck boost converter is a type of converter that can both step up and step down the input voltage, making it a highly efficient solution for a wide range of applications. Its operating temperature range of -40°C to +85°C makes it suitable for use in harsh environments. With an efficiency of up to 95%, this converter is an ideal choice for applications that require high power density and low electromagnetic interference.
The DC buck boost converter is an automatic buck boost converter, which means it can automatically switch between buck mode and boost mode, depending on the input and output voltage levels. This feature makes this converter highly adaptable to different input and load conditions.
The DC buck boost converter can be used in a variety of scenarios, such as in power supply systems for telecommunications equipment, automotive electronics, and industrial automation. It can also be used in portable electronic devices, such as smartphones and tablets, to provide efficient and stable power supply. Additionally, this converter can be used in renewable energy systems, such as solar and wind power, to efficiently convert the DC voltage to the required levels.
The DC buck boost converter is controlled by pulse-width modulation (PWM), which allows for precise control of the output voltage and current. The package type for this converter is SOT-23-6, which is a small and compact package that allows for easy integration into different applications.
Customization:
The output current range is up to 2A, while the output voltage range is 1.25V-35V. The input voltage range is 3.5V-32V. The dimensions of the converter are 17.8mm X 11.7mm X 3.8mm and the topology is Buck-Boost.
Our product customization services include options for auto buck boost converter, 12v buck boost converter, and more. Contact us for more information.
Packing and Shipping:
The DC Buck Boost Converter will be packaged securely in a cardboard box to prevent damage during shipping. The box will include the product, user manual, and any necessary accessories.
Product Shipping:
We offer worldwide shipping for the DC Buck Boost Converter. Shipping will be calculated based on the destination and shipping method selected at checkout. Orders will be shipped within 2 business days of purchase and tracking information will be provided.
